1. Pure digital circuit design: Using imported chips and the world's advanced FPGA algorithm, it has realized multi-threaded high-speed parallel (can process various input and output signals required by electromagnetic induction aluminum foil sealing machine at the same time), and the processing speed is dozens of times faster that single-chip microcomputer. The sealing is more stable, and the equipment failure rate is lower. 2. Modular all-digital high-precision circuit control system ensures stable output and is not affected by mains fluctuations. 3. Adjustable power switching power supply, no need to preheat when starting up, easy to operate. 4. The heating sensor,main unit can be interchanged for the equipment of the same model, effectively reduce the cost.
5. Brand-new core module: equipment anti-corrosion, moisture-proof, dust-proof, stable performance, long service life, convenient maintenance, and greatly reduce costs.
Standard:one Main unit,one Support cart,one Heating sensor
Applications
The device is a economical air-cooled desktops, integrated conveyor belt design, stable operation, meet the needs of all kinds of conventional container seal generally, especially suitable for the production line of small and medium-sized enterprises.
Technical
Input:AC 220V±10%，50/60Hz Output:2000WMAX (adjustable) Conveying speed:40～180bottles per minute Sealing Diameter:Φ20 mm～Φ80 mm,or Φ70 mm～Φ110 mm(select one from two) Sealing Height(from ground): 920 mm-1280 mm
